Spider adalah storage engine di MariaDB yang memungkinkan transparent sharding dan distributed database architecture. Setelah mengimplementasikan sharding untuk high-scale applications, saya akan berbagi setup dan best practices.

Apa itu Spider Storage Engine?

Konsep Sharding dengan Spider

Spider memungkinkan:
– Transparent sharding: Data terdistribusi tapi diakses sebagai satu table
– Distributed queries: Query berjalan di multiple nodes
– Automatic routing: Spider mengarahkan queries ke shards yang tepat

Arsitektur

Application → Spider Node → Shard 1
                         → Shard 2
                         → Shard 3

Setup Spider

1. Install Spider

# Spider biasanya sudah included dalam MariaDB
# Cek apakah sudah tersedia
mysql -e "INSTALL SONAME 'ha_spider';"
Atau enable di my.cnf
[mysqld]
plugin-load-add=ha_spider

2. Configure Spider Node

-- Spider node (frontend)
CREATE SERVER shard1
FOREIGN DATA WRAPPER mysql
OPTIONS (
    HOST '192.168.1.101',
    DATABASE 'shard_db',
    USER 'spider_user',
    PASSWORD 'password',
    PORT 3306
);
CREATE SERVER shard2
FOREIGN DATA WRAPPER mysql
OPTIONS (
HOST '192.168.1.102',
DATABASE 'shard_db',
USER 'spider_user',
PASSWORD 'password',
PORT 3306
);

3. Create Sharded Table

-- Create Spider table dengan sharding
CREATE TABLE users (
    id INT,
    username VARCHAR(50),
    email VARCHAR(100),
    created_at TIMESTAMP,
-- Shard key (partitioning)
PARTITION BY LIST COLUMNS(id) (
    PARTITION p1 VALUES IN (1, 2, 3) COMMENT 'shard1',
    PARTITION p2 VALUES IN (4, 5, 6) COMMENT 'shard2'
)
) ENGINE=SPIDER
COMMENT 'wrapper "mysql", table "users"';
-- Atau dengan HASH sharding
CREATE TABLE orders (
id INT,
user_id INT,
total DECIMAL(10,2),
PARTITION BY HASH(user_id) PARTITIONS 4
) ENGINE=SPIDER;
Configuration Options
1. Spider System Variables
# my.cnf
[mysqld]
# Spider settings
spider_internal_sql_log_off = 1
spider_direct_sql = 1
spider_support_xa = 1
Connection settings
spider_connect_timeout = 10
spider_net_read_timeout = 30
spider_net_write_timeout = 30
2. Table Options
CREATE TABLE distributed_table (...) ENGINE=SPIDER
COMMENT '
    wrapper "mysql",
    srv "shard1,shard2,shard3",
    table "table_name",
    mbk "1"
';
Use Cases
1. Large Scale Data
-- Sharding untuk big data
CREATE TABLE logs (
    log_id BIGINT,
    log_time DATETIME,
    level VARCHAR(10),
    message TEXT
) ENGINE=SPIDER
PARTITION BY RANGE (YEAR(log_time)) (
    PARTITION p2022 VALUES LESS THAN (2023) COMMENT 'srv "shard1"',
    PARTITION p2023 VALUES LESS THAN (2024) COMMENT 'srv "shard2"',
    PARTITION p2024 VALUES LESS THAN (2025) COMMENT 'srv "shard3"'
);
2. Geographic Distribution
-- Sharding berdasarkan region
CREATE TABLE customers (
    customer_id INT,
    region VARCHAR(20),
    name VARCHAR(100)
) ENGINE=SPIDER
PARTITION BY LIST COLUMNS(region) (
    PARTITION asia VALUES IN ('SG', 'JP', 'ID') COMMENT 'srv "asia_shard"',
    PARTITION europe VALUES IN ('UK', 'DE', 'FR') COMMENT 'srv "eu_shard"',
    PARTITION americas VALUES IN ('US', 'CA', 'BR') COMMENT 'srv "us_shard"'
);
Query Distribution
1. Automatic Query Routing
-- Spider otomatis route query ke shard yang tepat
SELECT * FROM users WHERE id = 5;
-- Akan di-route ke shard2 (berdasarkan partitioning)
SELECT * FROM orders WHERE user_id = 123;
-- Akan di-route berdasarkan hash(user_id)
2. Aggregations
-- Aggregations across shards
SELECT region, COUNT(*) as customer_count
FROM customers
GROUP BY region;
-- Spider akan query semua shards dan aggregate results
Monitoring Spider
1. Spider Status
-- Check Spider servers
SELECT * FROM mysql.servers;
-- Check Spider table status
SHOW TABLE STATUS WHERE Engine = 'SPIDER';
2. Performance Monitoring
-- Spider statistics
SHOW STATUS LIKE 'Spider%';
-- Check slow queries
SELECT * FROM mysql.slow_log
WHERE db LIKE '%spider%'
ORDER BY query_time DESC;
Best Practices
Choose shard key wisely: Harus sering digunakan dalam WHERE
Consistent sharding: Gunakan same shard key untuk related tables
Monitor connections: Spider menggunakan banyak connections
Test failover: Spider bisa handle shard failures
Balance load: Monitor shard utilization
Kesimpulan
Spider memungkinkan:
– Transparent sharding tanpa application changes
– Horizontal scalability
– Geographic distribution
– High availability dengan failover
Untuk aplikasi dengan massive data dan high traffic, Spider adalah solusi sharding yang powerful.
